PrimaKlima - PK250 ECblue, 1450 m³/h

The PrimaKlima PK250 ECblue is a highly efficient inline fan with an ebm-papst EC motor optimally matched to the housing and a backward-curved impeller.

The RJ45 port enables individual control or operation with the PrimaKlima ECTC-1M-Digital controller.

Advantages:

• Highly efficient ebm-papst EC motor
• Impeller with backward-curved blades
• Aerodynamically optimised design
• Two-part housing made from extremely impact-resistant and durable polyamide (nylon)
• Connections, capacitor and control electronics fully integrated into the housing
• RJ45 interface for control

Properties:

• Flange: 250 mm
• Maximum airflow: 1450 m³/h
• Power consumption: 0–170 W
• Electrical supply: 230 V, 50/60 Hz, 0.74 A
• Maximum operating temperature: 50 °C
• Dimensions (W × H): 369 × 276 mm
• Weight: 3.8 kg
• Plug: Swiss plug, pre-wired

Scope of delivery:

• 1 × PrimaKlima PK250 ECblue inline fan with Swiss plug
